Pedrollo NK Multi-stage Submersible Pump

Description

Pedrollo NK Multi-stage Submersible Pump

INSTALLATION & USE

The NK Pedrollo pumps are suitable for use with clean water in domestic, civil, and agricultural applications such as the distribution of water in combination with pressure sets, for the irrigation of gardens and allotments, and for pressure boosting, etc.

This pump is available in either single or three-phase. Single-phase pumps are available with or without a fitted float switch.

Models include:
Single Phase: NKm2/3-N | NKm2/4-N | NKm2/5-N | NKm2/6-N | NKm4/3-N | NKm4/4-N | NKm4/5-N | NKm4/6-N | NK8/4-N

CONSTRUCTION

Stainless Steel AISI 304 External Sleeve, complete with a threaded delivery port in compliance with ISO 228/1
Stainless Steel AISI 304 Suction Filter
Stainless Steel AISI 304 motor sleeve
Noryl GFN2V Impellers and Diffusers
Stainless steel motor shaft EN 10088-3 – 1.4104
Complete with a 20 m long power cable
Power Supply: 230V Single Phase (230/1/50) or 400V Three Phase (400/3/50)
Ports: 1 1/4″

PERFORMANCE RANGE

Flow rate up to  160l/min (9.6 m³/h)
Head up to 95m

APPLICATION LIMITS

– Maximum liquid temperature 40°C
– Maximum sand content 50 g/m³ (with a sufficiently long power cable)
– 20m maximum immersion depth
– Continuous service S1
